MT3211 is a highly sensitive wide dynamic range digital ambient light sensor (ALS) with a low-profile and small footprint.

It includes Photopic, Clear and Flicker photodiodes (PDs), which provide ambient light and flicker frequency information of the ambient light source.

MT3211 architecture accurately measures the ambient light, provides ultra-high sensitivity for luminance detection and very useful for smart lighting management, especially in robust backlight brightness, display appearance, camera flicker control.

• Excellent light transmittance designed for best sensitivity


• Output ALS and Flicker in parallel

• Fully digital control with I2C interface operating within 1.2V ~ 3.6V VDD range

• Wide range of VDD voltage: 1.7V ~ 2.0V

• Idle mode current: 2μA

• Sleep mode current: 0.35μA

• Enables superior detections

1024 bytes FIFO

Up to 7kHz flicker detection

16-bit digital data output

Programmable gain and integration time

4096x dynamic range by gain adjustment

Flicker-immune ALS sensing with programmable integration time

Temperature compensation

Approximates human eye response

1MHz fast I2C Interface

• RoHS compliant lead-free OLGA package for smart lighting devices
